BASE INFO

E-SYSTEM

BOSCH Performance Line CX, Smart System G4, 750Wh Battery

DISTANCE

180 Km

MAX. TORQUE

85Nm / 400%

WEIGHT

28.25 kg

ISO and EN norm

LOAD CAPACITY

150 Kg

E- BIKE PARTS

MOTOR

BOSCH PerformanceLine CX, Smart System,36V, 250W, 85Nm, , 400% support

CHARGER

BOSCH 4A charger

BATTERY

BOSCH BATTERY POWER TUBE 750

DISPLAY

BOSCH KIOX 300

SWITCH

BOSCH LED REMOTE

FRAMESET

FRAME

Aluminium monotube frame for BOSCH CX Performance SMART SYSTEM drive unit, Up to 750Wh battery, 29/27,5 wheels compatible. Ready for dropper seat post and suspension dropper seatpost.

SUSPENSION FORK

RockShox Judy Silver TK, Tapered, SoloAir, 15x110mm axle, 100mm travel

HEADSET

ACROS ZS56/ZS56

SUSPENSION TRAVEL FRONT

100mm

DRIVETRAIN

GEAR RANGE

1x10, 11-48, 436%

SHIFTERS RIGHT

SHIMANO CUES SL-U6000 RapidFire Plus, 10-speed

REAR DERAILLEUR

SHIMANO RD-U6000

CRANKSET

ONE1 EC39-BH4-F13-ISIS-L/R, 38T

CHAINRING

SAMOX 38T

CASSETTE

SHIMANO CS-LG300-10, 11-48T

CHAIN

SHIMANO CN-LG500

BRAKING SYSTEM

BRAKE FRONT

SHIMANO MT200

ROTOR FRONT

SHIMANO SM-RT10, 180mm

BRAKE REAR

SHIMANO MT200

ROTOR REAR

SHIMANO SM-RT10, 180mm

WHEELS

HUB FRONT

SHIMANO HB-TC500-15-B

RIM FRONT

STARS J30

TIRE FRONT

WTB GROOV-E Comp, 27.5x2.40

HUB REAR

SHIMANO, FH-QC300

RIM REAR

STARS J30

TIRE REAR

WTB GROOV-E Comp, 27.5x2.40

SPOKES

Sapim Leader, Stainless Black with secure lock nipples

COCKPIT

STEM

TDS-C342 Alloy, 31.8mm, e45, +3°

HANDLEBAR

Velobel, aluminium riser 40, ergo handlebar

BELL

Widek Paperclip e-bike

GRIPS

HERRMANS CLIK DD37

PARTS

SADDLE

SELLE ROYAL Essenza Moderate

SEATPOST

ONE1 Alloy, SP S405, 30.9mm

PEDALS

Flat, Glass Fiber Reinforced Nylon, with reflector

CITY/ SUV SET

FRONT LIGHT

AXA, BLUELINE 30

REAR LIGHT

SPANNINGA Pling XE

FENDER

ALLOY FULL COVER FENDERS

CARRIER

Delta Carrier, AVS, max. load 27kg

KICKSTAND

ATRAN VELO, REX

FRAME LOCK

AXA Block XXL
